Docker镜像仓库全解析：分类、搭建与使用

## Docker镜像仓库的概念 在Docker生态系统中，Docker镜像仓库（或称为Docker Registry）是一个存储和分发Docker镜像的服务。它类似于其他编程语言中的包管理系统，允许开发者上传、下载和管理Docker镜像。Docker官方提供了一个公共的镜像仓库服务，称为`Docker Hub`，但你也可以在自己的服务器上运行私有镜像仓库。 ### Docker仓库的特点 - 存储镜像：Docker镜像仓库用来存储Docker镜像。这些镜像可以是官方提供的，也可以是用户自己创建的。 - 版本控制：每个镜像可以有多个版本（tags），这使得用户可以轻松地回溯到之前的版本或者使用特定的版本。 - 分发：通过镜像仓库，用户可以轻松地共享和分发他们的Docker镜像给其他用户或团队。 - 认证和安全：许多镜像仓库支持基于角色的访问控制（RBAC），允许管理员控制谁可以访问哪些镜像。 ### Docker镜像仓库分类 Docker镜像仓库主要分为公共镜像仓库和私有镜像仓库。 #### 公共镜像仓库 公共镜像仓库为Docker官方提供，称为`Docker Hub`，地址： 当然，现在目前各厂商也相继推出了公共的镜像仓库。 目前`Docker hub`在国内访问不了，需要配置一些代理才能够访问，可以参考下列： ```csharp sudo mkdir -p /etc/docker sudo tee /etc/docker/daemon.json <5000/tcp, [::]:5000->5000/tcp registry ``` ### 测试访问   ### 配置docker准许http访问 docker默认是使用https进行通信的，我们这里配置一下docker使用http访问仓库 示例：如果不配置http访问，推送镜像时会报错 ```csharp # 给镜像打一个tag [root@lb ~]# docker tag mysql:5.7 10.0.0.10:5000/huangsir/mysql:5.7 # 推送镜像 [root@lb ~]# docker push 10.0.0.10:5000/huangsir/mysql:5.7 The push refers to repository [10.0.0.10:5000/huangsir/mysql] Get "https://10.0.0.10:5000/v2/": http: server gave HTTP response to HTTPS client ``` #### 给docker配置http 需要在`/etc/docker/daemon.json`文件中添加`{ "insecure-registries": ["10.0.0.10:5000"] }`这行配置，让 Docker 认为该地址是安全的，当然这里的IP也可以换成域名 ```csharp [root@lb ~]# cat /etc/docker/daemon.json { "registry-mirrors": [ ... ], "insecure-registries": [ "10.0.0.10:5000" ] } [root@lb ~]# systemctl daemon-reload [root@lb ~]# systemctl restart docker ``` 再次推送镜像查看： ```csharp [root@lb ~]# docker push 10.0.0.10:5000/huangsir/mysql:5.7 The push refers to repository [10.0.0.10:5000/huangsir/mysql] 441e16cac4fe: Pushed 73cb62467b8f: Pushed 337ec6bae222: Pushed 532b66f4569d: Pushed 0d9e9a9ce9e4: Pushed 4555572a6bb2: Pushed 8527ccd6bd85: Pushed d76a5f910f6b: Pushed 8b2952eb02aa: Pushed 7ff7abf4911b: Pushed cff044e18624: Pushed 5.7: digest: sha256:4b6c4935195233bc10b617df3cc725a9ddd5a7f10351a7bf573bea0b5ded7649 size: 2618 [root@lb ~]# curl {"repositories":["huangsir/mysql"]} ``` ### 如何查看仓库中有哪些镜像的版本 `curl ` ```csharp [root@lb ~]# curl {"name":"huangsir/mysql","tags":["5.7"]} ``` ### registry配置用户名密码进行访问 创建一个目录用于存放认证信息，并使用htpasswd命令创建用户名和密码。例如： ```csharp [root@lb ~]# mkdir -p /data/docker/auth [root@lb ~]# htpasswd -Bbn admin 123456 > /data/docker/auth/htpasswd [root@lb ~]# cat /data/docker/auth/htpasswd admin:$2y$05$mAp6m7bU5RlQvG808YmRDu6.vgg3q4cMOcCCDZYWkquBqaJrGQtLO ``` 这会创建一个名为admin的用户，密码为123456。 #### 创建容器 ```csharp [root@lb ~]# docker run -d --name registry -p 5000:5000 --restart always \ -v /data/docker/registry:/var/lib/registry \ -v /data/docker/auth:/auth \ -e "REGISTRY_AUTH=htpasswd" \ -e "REGISTRY_AUTH_HTPASSWD_REALM=Registry Realm" \ -e "REGISTRY_AUTH_HTPASSWD_PATH=/auth/htpasswd" \ registry b355fdcdb98093ca05d66dd0ddd9246af2e8e81653d8975ed6bcbb7a3fd9b234 [root@lb ~]# docker ps -a CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES b355fdcdb980 registry "/entrypoint.sh /etc…" 4 seconds ago Up 4 seconds 0.0.0.0:5000->5000/tcp, [::]:5000->5000/tcp registry ``` #### 测试拉取镜像 ```csharp # 拉取镜像时提示需要进行验证 [root@lb ~]# docker pull 10.0.0.10:5000/huangsir/mysql:5.7 Error response from daemon: Head "http://10.0.0.10:5000/v2/huangsir/mysql/manifests/5.7": no basic auth credentials ``` #### 登录docker镜像 ```csharp docker login -u admin -p 123456 10.0.0.10:5000 ``` 最后返回登录成功的信息即可 ## 私有镜像仓库之harbor搭建使用 docker搭建harbor仓库需要Docker compose！！！，需要安装教程的同学可以参考这篇文章：一文搞懂Docker Compose harbor仓库地址： ### 部署harbor ```csharp # 下载harbor [root@lb ~]# wget [root@lb ~]# ll harbor-offline-installer-v2.13.0.tgz -rw-r--r-- 1 root root 657690441 Apr 20 13:47 harbor-offline-installer-v2.13.0.tgz # 解压 [root@lb ~]# tar -xvf harbor-offline-installer-v2.13.0.tgz harbor/harbor.v2.13.0.tar.gz harbor/prepare harbor/LICENSE harbor/install.sh harbor/common.sh harbor/harbor.yml.tmpl ``` #### 修改harbor的配置文件 ```csharp [root@lb ~/harbor]# cd harbor [root@lb ~/harbor]# mv harbor.yml.tmpl harbor.yml # 只需修改下面的即可 [root@lb ~/harbor]# vim harbor.yml # 访问域名。这里先随便填写一个域名即可 hostname: reg.huangsir.com ##### 将https相关的内容注释掉 #https: # https port for harbor, default is 443 #port: 443 # The path of cert and key files for nginx #certificate: /your/certificate/path #private_key: /your/private/key/path # enable strong ssl ciphers (default: false) # strong_ssl_ciphers: false ## 修改用户密码 harbor_admin_password: 123456 ## 修改挂载的存储卷 data_volume: /data/harbor/regsitry ``` #### 安装harbor harbor仓库默认使用80端口，需要确保宿主机的80端口没有被占用，或者修改`docker-compose.yaml`文件，将80端口进行修改 ```csharp # 先创建存储卷 [root@lb ~/harbor]# mkdir -p /data/harbor/regsitry # 执行安装前置校验脚本，最后输出Successfully即可 [root@lb ~/harbor]# ./prepare ......#省略万字内容 Successfully called func: create_root_cert Generated configuration file: /compose_location/docker-compose.yml Clean up the input dir # 执行安装，最后输出successfully即可 [root@lb ~/harbor]# ./install.sh .....#省略万字内容 [+] Running 10/10 ✔ Network harbor_harbor Created 0.0s ✔ Container harbor-log Started 0.3s ✔ Container harbor-portal Started 1.4s ✔ Container registryctl Started 1.2s ✔ Container registry Started 1.4s ✔ Container harbor-db Started 1.3s ✔ Container redis Started 1.2s ✔ Container harbor-core Started 1.7s ✔ Container harbor-jobservice Started 2.5s ✔ Container nginx Started 2.6s ✔ ----Harbor has been installed and started successfully.---- # 查看镜像运行状况 [root@lb ~/harbor]# docker-compose ps NAME IMAGE COMMAND SERVICE CREATED STATUS PORTS harbor-core goharbor/harbor-core:v2.13.0 "/harbor/entrypoint.…" core 55 seconds ago Up 53 seconds (healthy) harbor-db goharbor/harbor-db:v2.13.0 "/docker-entrypoint.…" postgresql 55 seconds ago Up 54 seconds (healthy) harbor-jobservice goharbor/harbor-jobservice:v2.13.0 "/harbor/entrypoint.…" jobservice 55 seconds ago Up 46 seconds (healthy) harbor-log goharbor/harbor-log:v2.13.0 "/bin/sh -c /usr/loc…" log 55 seconds ago Up 54 seconds (healthy) 127.0.0.1:1514->10514/tcp harbor-portal goharbor/harbor-portal:v2.13.0 "nginx -g 'daemon of…" portal 55 seconds ago Up 54 seconds (healthy) nginx goharbor/nginx-photon:v2.13.0 "nginx -g 'daemon of…" proxy 55 seconds ago Up 53 seconds (healthy) 0.0.0.0:80->8080/tcp, [::]:80->8080/tcp redis goharbor/redis-photon:v2.13.0 "redis-server /etc/r…" redis 55 seconds ago Up 54 seconds (healthy) registry goharbor/registry-photon:v2.13.0 "/home/harbor/entryp…" registry 55 seconds ago Up 54 seconds (healthy) registryctl goharbor/harbor-registryctl:v2.13.0 "/home/harbor/start.…" registryctl 55 seconds ago Up 54 seconds (healthy) ``` ### 浏览器访问harbor  或者使用你配置好的域名访问也可以  #### 登录harbor： 用户名：admin 密码：前面我们配置的，123456  ### 使用harbor仓库 #### docker配置准许harbor仓库进行http访问 需要在`/etc/docker/daemon.json`文件中添加`{ "insecure-registries": ["reg.huangsir.com"] }`这行配置，让 Docker 认为该地址是安全的，当然这里的IP也可以换成域名 ```csharp [root@lb ~]# cat /etc/docker/daemon.json { "registry-mirrors": [ ... ], "insecure-registries": [ "10.0.0.10:5000", "reg.huangsir.com" ] } [root@lb ~]# systemctl daemon-reload [root@lb ~]# systemctl restart docker ``` #### 登录harbor仓库 ```csharp # 本地做一些hosts解析 [root@lb ~/harbor]# echo '10.0.0.10 reg.huangsir.com' >> /etc/hosts # 登录 [root@lb ~/harbor]# docker login -u admin -p 123456 reg.huangsir.com WARNING! Using --password via the CLI is insecure. Use --password-stdin. WARNING! Your credentials are stored unencrypted in '/root/.docker/config.json'. Configure a credential helper to remove this warning. See Login Succeeded ``` #### 推送镜像至harbor仓库 在harbor仓库新建一个项目   推送镜像 ```csharp # 打标签 [root@lb ~/harbor]# docker tag mysql:5.7 reg.huangsir.com/private/mysql:5.7 # 推送镜像 [root@lb ~/harbor]# docker push reg.huangsir.com/private/mysql:5.7 The push refers to repository [reg.huangsir.com/private/mysql] 441e16cac4fe: Mounted from library/mysql 73cb62467b8f: Mounted from library/mysql 337ec6bae222: Pushed 532b66f4569d: Mounted from library/mysql 0d9e9a9ce9e4: Pushed 4555572a6bb2: Pushed 8527ccd6bd85: Pushed d76a5f910f6b: Pushed 8b2952eb02aa: Pushed 7ff7abf4911b: Pushed cff044e18624: Pushed 5.7: digest: sha256:4b6c4935195233bc10b617df3cc725a9ddd5a7f10351a7bf573bea0b5ded7649 size: 2618 ``` 通过浏览器查看，发现我们的镜像已经推送成功了  ### harbor仓库配置https访问 修改harbor.yml文件，将https部分放开即可 ```csharp [root@lb ~/harbor]# vim harbor.yml https: # https的端口 port: 443 # 公钥 certificate: /your/certificate/path # 私钥 private_key: /your/private/key/path # 修改完成之后重启即可 [root@lb ~/harbor]# docker-compose restart ``` ## 私有镜像仓库之阿里云镜像仓库（ACR）使用 阿里云镜像仓库地址： 阿里云镜像仓库个人版可以面试试用，但是有限制，只有三个命名空间，三百个仓库  ### 登录到阿里云镜像仓库 点击访问凭证即可，我们可以设置固定密码，后续登录就使用改密码进行登录  ```csharp [root@lb ~/harbor]# docker login --username=灬halo丨少年 crpi-jzkigw8wlyp1a5sg.cn-hangzhou.personal.cr.aliyuncs.com i Info → A Personal Access Token (PAT) can be used instead. To create a PAT, visit Password: WARNING! Your credentials are stored unencrypted in '/root/.docker/config.json'. Configure a credential helper to remove this warning. See Login Succeeded ``` ### 新建命名空间和镜像仓库 #### 新建命名空间   #### 新建镜像仓库  选择本地仓库  duang，我们的镜像仓库就建好了  ### 测试上传镜像 ```csharp [root@lb ~/harbor]# docker tag mysql:5.7 crpi-jzkigw8wlyp1a5sg.cn-hangzhou.personal.cr.aliyuncs.com/huangxin/mysql:5.7 [root@lb ~/harbor]# docker push crpi-jzkigw8wlyp1a5sg.cn-hangzhou.personal.cr.aliyuncs.com/huangxin/mysql:5.7 The push refers to repository [crpi-jzkigw8wlyp1a5sg.cn-hangzhou.personal.cr.aliyuncs.com/huangxin/mysql] 441e16cac4fe: Pushed 73cb62467b8f: Pushed 337ec6bae222: Pushed 532b66f4569d: Pushed 0d9e9a9ce9e4: Pushed 4555572a6bb2: Pushed 8527ccd6bd85: Pushed d76a5f910f6b: Pushed 8b2952eb02aa: Pushed 7ff7abf4911b: Pushed cff044e18624: Pushed 5.7: digest: sha256:4b6c4935195233bc10b617df3cc725a9ddd5a7f10351a7bf573bea0b5ded7649 size: 2618 ``` 查看阿里云镜像仓库
